YASKAWA HV600 User Manual

Parameter Details
5
5.14 Z: Bypass Parameters
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 441
■ Z1-98: Minimum Drive SW Ver
No.
(Hex.)
Name Description
Default
(Range)
Z1-98
(8627)
Expert
Minimum Drive SW Ver “WARNING: If these parameters are changed, undesired operation of the bypass system could occur.
These parameters should only be changed under guidance of Yaskawa technical support (1-800-
YASKAWA).”
01011
00000 - 65535
■ Z1-99: Maximum Drive SW Ver
No.
(Hex.)
Name Description
Default
(Range)
Z1-99
(8628)
Expert
Maximum Drive SW Ver “WARNING: If these parameters are changed, undesired operation of the bypass system could occur.
These parameters should only be changed under guidance of Yaskawa technical support (1-800-
YASKAWA).”
01011
00000 - 65535
◆ Z2: Bypass Control Input/Output
■ Z2-01 to Z2-08 Digital Input 1 to 8 Function Selection
The drive has 8 digital input terminals. Refer to Table 5.70 for default settings and functions.
Table 5.70 Digital Input Default Settings and Functions
No. Name Default Function
Z2-01 Digital Input 1 Function Select (TB2-1) 21 Run (AUTO)
Z2-02 Digital Input 2 Function Select (TB2-2) 22 Run Enable - Safety (NC)
Z2-03 Digital Input 3 Function Select (TB2-3) 23 Run Interlock (BAS)
Z2-04 Digital Input 4 Function Select (TB2-4) 24 Remote Transfer to Bypass
Z2-05 Digital Input 5 Function Select (TB2-5) 25 Emergency Override Bypass
Z2-06 Digital Input 6 Function Select (TB2-6) 0 Not Used
Z2-07 Digital Input 7 Function Select (TB2-7) 0 Not Used
Z2-08 Digital Input 8 Function Select (TB2-8) 0 or 29 Not Used or External Overload Motor 1 (NC)
Table 5.71 Digital Input Setting Values
Setting Value Function Reference
0 Not Used
444
1 Drive S1 Passthrough
444
2 Drive S2 Passthrough
444
3 Drive S3 Passthrough
444
4 Drive S4 Passthrough
444
5 Drive S5 Passthrough
444
6 Drive S6 Passthrough
444
7 Drive S7 Passthrough
445
21 Run (AUTO)
445
22 Run Enable - Safety (NC)
445
23 Run Interlock (BAS)
445
24 Remote Transfer to Bypass
445
25 Emergency Override Bypass
445
26 Emergency Override Drive (FWD)
445
27 Motor OR Select
445
28 Motor AND Select
445
Setting Value Function Reference
29 External Overload Motor 1 (NC)
445
30 External Overload Motor 2 (NC)
446
31 HAND Select
446
32 AUTO Select
446
33 Drive/Bypass Select
446
34 Fault Reset
446
35 External Fault (EF0)
446
36 External Fault (EFB)
446
37 Run Reverse (AUTO)
446
38 Fire Stat Switch (NC)
446
39 Freeze Stat Switch (NC)
446
40 Smoke Alarm (NC)
446
41 OverPressure Switch (NC)
447
42 Low Suction Switch (NC)
447
43 Vibration Switch (NC)
447
44 Emergency Override Drive (REV)
447
