4.4 Keypad Operation
160 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
5. Push / to select [No], then push .
• [No]: The keypad will not show the Initial Setup Screen when the drive is energized.
• [Yes]: The keypad will show the Initial Setup Screen when the drive is energized.
â—† Start Data Logging
The data log function saves drive status information. Monitors Ux-xx are the source of log information. The procedure
in this section shows how to start logging data.
You can record a maximum of 10 monitors.
1. Insert a microSD card in the keypad.
2. Push (Home) to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If the screen does not show [Home] for , push (Back), and then push to show [Home].
3. Push (Menu).
4. Push or to select [Diagnostic Tools], then push .
5. Push or to select [Data Logger], then push .
To Next Page
