7.9 Drive Derating
544 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Bypass Model Drive Model
Rated Current (A)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
A154 2169 169 169 135.2 112.7 -
A192 2211 211 211 168.8 140.7 -
A248 2273 273 273 218.4 182 -
■ 480 V Models
Table 7.24 Carrier Frequency and Rated Current Derating
Bypass Model Drive Model
Rated Current (A)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
B001 to B004 4005 4.8 4.8 4.0 3.5 2.9
B007 4008 7.6 7.6 6.4 5.6 4.6
B011 4011 11.0 11.0 9.2 8.1 6.6
B014 4014 14.0 14.0 11.8 10.3 8.4
B021 4021 21.0 21.0 17.6 15.4 12.6
B027 4027 27.0 27.0 22.7 19.8 16.2
B034 4034 34.0 34.0 28.6 24.9 20.4
B040 4040 40.0 40.0 33.6 29.3 24.0
B052 4052 52.0 52.0 43.7 38.1 31.2
B065 4065 65.0 65.0 54.6 47.7 39.0
B077 4077 77.0 77.0 64.7 56.5 46.2
B096 4096 96.0 96.0 80.6 70.4 57.6
B124 4124 124 124 99.2 92.7 -
B156 4156 156 156 124.8 104 -
B180 4180 180 180 144 120 -
B240 4240 240 224 176 144 -
B302 4302 302 281.9 221.5 181.2 -
◆ Derating Depending on Ambient Temperature
When you install drives in a place where ambient temperatures are higher than the rated conditions or install drives
side-by-side in the enclosure panel, set L8-12 [Ambient Temperature] and L8-35 [Installation Method Selection].
Derate the output current as specified in Figure 7.1 to Figure 7.4.
No.
(Hex.)
Name Description
Default
(Range)
L8-12
(04B8)
Ambient Temperature
Setting
Sets the ambient temperature of the drive installation area. 40 °C
(Determined by L8-35)
No.
(Hex.)
Name Description
Default
(Range)
L8-35
(04EC)
Installation Method
Selection
Sets the type of drive installation. 2
(0 - 3)
Note:
The drive will detect an oPE02 [Parameter Range Setting Error] in these conditions:
• If you set L8-12 = 60 °C and L8-35 = 1 or 3 for models 2011 to 2114 and 4005 to 4124
• If you set L8-35 = 1 or 3 for models 2143 to 2273 and 4156 to 4302
0 : IP20/UL Open Type
