Receiving
1
1.2 Catalog Code and Nameplate Check
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 23
1.2 Catalog Code and Nameplate Check
Please examine these items after you received the bypass:
• Examine the bypass and drive for damage or missing parts. Immediately contact the shipping company if there is
damage. The Yaskawa warranty does not cover damage from shipping.
• Examine the model number on the bypass nameplate to make sure that you received the correct model.
• If you received a product different than what you ordered or your product has a defect, contact Yaskawa or your
nearest sales representative.
â—† Narrow Bypass Nameplate
A - Input specifications
B - Output specifications
C - Replacement fuse specifications
D - Serial number
E - Bypass model number
F - Schematic document number
Figure 1.1 Narrow Bypass Nameplate Location Example
