5.14 Z: Bypass Parameters
452 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
28: Mirror HV600 M5-M6
Setting Value Function Description
28 Mirror HV600 M5-M6 The digital output activates when the HV600 drive digital output (M5-M6) is closed.
Use H2-03 [Term H2-03 – M5-M6 Function Selection] to set the M5-M6 digital output. Refer to H2: Digital Outputs
on page 619 for more information about setting values.
Note:
When the drive unit is OFF (in Bypass Mode in a 3-contactor configured bypass), this output will be OFF.
ON : Digital Output M5-M6 on HV600 is closed
OFF : Digital Output M5-M6 on HV600 is open
99: Not Used
Setting Value Function Description
99 Not Used This setting allows serial communications to control the output.
■ Z2-30: Analog Input Signal Level Select
No.
(Hex.)
Name Description
Default
(Range)
Z2-30
(8580)
Analog Input Signal Level
Select
Sets the input signal level for MFAI terminal A1. 0
(0 - 3)
0 : 0 to 10V (Lower Limit at 0)
2 : 4 to 20 mA
3 : 0 to 20 mA
■ Z2-32: Analog Input Gain Setting
No.
(Hex.)
Name Description
Default
(Range)
Z2-32
(8582)
Analog Input Gain Setting Sets the gain of the analog signal input to MFAI terminal A1. 100.0%
(-999.9 - +999.9%)
■ Z2-33: Analog Input Bias Setting
No.
(Hex.)
Name Description
Default
(Range)
Z2-33
(8583)
Analog Input Bias Setting Sets the bias of the analog signal input to MFAI terminal A1. 0.0%
(-999.9 - +999.9%)
◆ Z3: Bypass Control Serial Comm
■ Z3-12: Network Digital Inputs
No.
(Hex.)
Name Description
Default
(Range)
Z3-12
(850B)
Network Digital Inputs Enables and disables control of the digital inputs over a network. It is not necessary to wire to the
physical digital input.
0
(0, 1)
0 : Disabled
Serial communications physical digital inputs are ignored.
For MEMOBUS/Modbus (H5-08 = 0): Command Register 8402H is disabled.
For Metasys N2 (H5-08 = 1): Binary Outputs B05, B06, B07, B08, and B09 are disabled.
For P1 Apogee (H5-08 = 2): Points LDO44, LDO45, LDO46, LDO47, and LDO48 are disabled.
For BACnet (H5-08 = 3): BV72, BV73, BV74, BV75, BV76, BV77, BV78, and BV79 are disabled.
1 : Enabled
