1.2 Catalog Code and Nameplate Check
26 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No. Description
4 Bypass output amps
5 Power options
• B: 3-contactor bypass
• G: Drive input service switch
• M: Lockable circuit breaker (100 kA SCCR Panel Rating)
6 Control options
• D: EtherNet/IP
• L: LonWorks
• W: Custom nameplate
■ Narrow Bypass Models, Drive Models, and Capacities
Table 1.2 Three-Phase AC 208 V Narrow Models and Capacities (NEMA Rating)
Bypass Model
H6BP
Capacity
Drive Catalog Code
HV60U
Electrical Schematic Weight (lb)
HP Input (A) Output (A)
D002 0.5 2.9 2.4 2011
DS.H6BP.01 55
D003 0.75 4.0 3.5 2011
DS.H6BP.01 55
D004 1 5.1 4.6 2011
DS.H6BP.01 55
D007 2 8.0 7.5 2011
DS.H6BP.01 55
D010 3 11.1 10.6 2011
DS.H6BP.01 55
D016 5 17.2 16.7 2017
DS.H6BP.01 55
D024 7.5 24.7 24.2 2024
DS.H6BP.01 62
D030 10 31.3 30.8 2031
DS.H6BP.01 64
D046 15 46.7 46.2 2046
DS.H6BP.01 87
D059 20 59.9 59.4 2059
DS.H6BP.01 92
D074 25 75.3 74.8 2075
DS.H6BP.01 128
Table 1.3 Three-Phase AC 480 V Narrow Models and Capacities (NEMA Rating)
Bypass Model
H6BP
Capacity
Drive Catalog Code
HV60U
Electrical Schematic Weight (lb)
HP Input (A) Output (A)
B001 0.75 1.8 1.6 4005
DS.H6BP.01 56
B002 1 2.3 2.1 4005
DS.H6BP.01 56
B003 2 3.6 3.4 4005
DS.H6BP.01 56
B004 3 5.0 4.8 4005
DS.H6BP.01 56
B007 4 7.8 7.6 4008
DS.H6BP.01 56
B011 7.5 11.2 11.0 4011
DS.H6BP.01 56
B014 10 14.2 14.0 4014
DS.H6BP.01 56
B021 15 21.2 21.0 4021
DS.H6BP.01 62
B027 20 27.2 27.0 4027
DS.H6BP.01 65
B034 25 34.2 34.0 4034
DS.H6BP.01 81
B040 30 40.2 40.0 4040
DS.H6BP.01 90
B052 40 52.2 52.0 4052
DS.H6BP.01 96
B065 50 65.2 65.0 4065
DS.H6BP.01 121
B077 60 77.2 77.0 4077
DS.H6BP.01 135
◆ How to Read Enclosed Bypass Catalog Codes
Use the information in Figure 1.5 and Table 1.4 to read the bypass catalog codes.
