YASKAWA HV600 User Manual

Specifications
7
7.5 240 V Enclosed Model Specifications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 535
7.5 240 V Enclosed Model Specifications
Table 7.8 240 V Enclosed Ratings
Model
A002 A003 A004 A006 A009 A015
Maximum Applicable Motor Output (HP)
*2
0.5 0.75 1 2 3 5
Input
Rated Input Current (A) 3.5 4.5 5.5 8.1 10.9 16.5
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
2.2
*3
3.2
*3
4.2
*3
6.8
*3
9.6
*3
15.2
*3
Minimum Applicable Motor
Current (A)
1.5 1.5 1.5 1.5 1.5 3.75
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-Phase 208 Vac
Maximum Output Frequency
(Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.9 240 V Enclosed Ratings
Model A022 A028 A042 A054 A068 A080
Maximum Applicable Motor Output
(HP)
*2
7.5 10 15 20 25 30
Input
Rated Input Current (A) 23.3 29.3 44.1 56.1 70.1 82.1
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
22
*3
28
*3
42
*3
54
*3
68
*3
80
*3
Minimum Applicable
Motor Current (A)
3.75 3.75 7.5 7.5 15 15
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage
(V)
Three-Phase 208 Vac
Maximum Output
Frequency (Hz)
240 Hz
