7.4 208 V Enclosed Model Specifications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 533
7.4 208 V Enclosed Model Specifications
Table 7.5 208 V Enclosed Ratings
Model D002 D003 D004 D007 D010 D016
Maximum Applicable Motor Output (HP)
*2
0.5 0.75 1 2 3 5
Input
Rated Input Current (A) 3.8 4.9 6.0 8.9 12.0 18.1
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
2.4
*3
3.5
*3
4.6
*3
7.5
*3
10.6
*3
16.7
*3
Minimum Applicable Motor
Current (A)
1.5 1.5 1.5 1.5 1.5 3.75
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-Phase 208 Vac
Maximum Output Frequency
(Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.6 208 V Enclosed Ratings
Model D024 D030 D046 D059 D074
Maximum Applicable Motor Output (HP)
*2
7.5 10 15 20 25
Input
Rated Input Current (A) 25.6 32.2 48.6 61.8 77.2
Rated Voltage
Rated Frequency
Three-Phase 208 Vac 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
24.2
*3
30.8
*3
46.2
*3
59.4
*3
74.8
*3
Minimum Applicable Motor
Current (A)
3.75 3.75 7.5 7.5 15
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage (V) Three-Phase 208 Vac
Maximum Output Frequency
(Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
