YASKAWA HV600 User Manual

Specifications
7
7.3 480 V Narrow Model Specifications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 531
7.3 480 V Narrow Model Specifications
Table 7.3 480 V Narrow Ratings
Model B001 B002 B003 B004 B007 B011 B014
Maximum Applicable Motor Output (HP)
*2
0.75 1 2 3 5 7.5 10
Input
Rated Input Current (A) 1.8 2.3 3.6 5.0 7.8 11.2 14.2
Rated Voltage
Rated Frequency
Three-Phase 480 Vac 50/60 Hz
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
1.6
*3
2.1
*3
3.4
*3
4.8
*3
7.6
*3
11.0
*3
14.0
*3
Minimum Applicable
Motor Current (A)
1.5 1.5 1.5 1.5 1.5 1.5 3.75
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage
(V)
Three-Phase 480 Vac
Maximum Output
Frequency (Hz)
240 Hz
Harmonics
Reduction
Input Power (kVA) Built-in
EMC
Filter (IEC/EN 61800-3
Category 2)
Built-in
*1 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output current of
the drive output amps must be equal to or more than the motor rated current.
*3 Carrier frequency is 5 kHz. You must derate the current to increase the carrier frequency.
Table 7.4 480 V Narrow Ratings
Model B021 B027 B034 B040 B052 B065 B077
Maximum Applicable Motor Output (HP)
*2
15 20 25 30 40 50 60
Input
Rated Input Current (A) 21.2 27.2 34.2 40.2 52.2 65.2 77.2
Rated Voltage
Rated Frequency
Three-Phase 480 Vac 50/60 Hz
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
Output
Rated Output Current (A)
21.0
*3
27.0
*3
34.0
*3
40.0
*3
52.0
*3
65.0
*3
77.0
*3
Minimum Applicable
Motor Current (A)
3.75 3.75 7.5 7.5 7.5 7.5 15
Overload Tolerance
110% of rated output current for 60 s
150% peak
Carrier Frequency
User adjustable between 1 and 12.5 kHz
(Maximum Frequency varies with Rated Output Capacity)
Maximum Output Voltage
(V)
Three-Phase 480 Vac
Maximum Output
Frequency (Hz)
240 Hz
