Specifications
7
7.9 Drive Derating
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 543
7.9 Drive Derating
You must derate the drive capacity to operate the drive above the rated temperature, altitude, and default carrier
frequency.
◆ Carrier Frequency Settings and Rated Current Values
Table 7.22, Table 7.23, and Table 7.24 show how the drive rated output current changes when the C6-02 [Carrier
Frequency Selection] value changes. The output current value changes linearly as the carrier frequency changes. You
can use the values from the tables to calculate a frequency that is not shown.
Note:
The drive will apply derating for the rated output current value based on the carrier frequency only to the reference output current value of
the oL2 [Drive Overload]. The derated value for the 100% rated output current in parameters and monitors will not be the same as the rated
output current value shown in the Model Specifications tables.
■ 208 V Models
Table 7.22 Carrier Frequency and Rated Current Derating
Bypass Model Drive Model
Rated Current (A)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
D002 to D010 2011 10.6 10.6 8.9 7.8 6.4
D016 2017 16.7 16.7 14.0 12.2 10.0
D024 2024 24.2 24.2 20.3 17.7 14.5
D030 2031 30.8 30.8 25.9 22.6 18.5
D046 2046 46.2 46.2 38.8 33.9 27.7
D059 2059 59.4 59.4 49.9 43.6 35.6
D074 2075 74.8 74.8 62.8 54.9 44.9
D088 2088 88.0 88.0 73.9 64.5 52.8
D114 2114 114 114 95.8 83.6 68.4
D143 2143 143 143 114.4 95.3 -
D169 2169 169 169 135.2 112.7 -
D211 2211 211 211 168.8 140.7 -
D273 2273 273 273 218.4 182 -
■ 240 V Models
Table 7.23 Carrier Frequency and Rated Current Derating
Bypass Model Drive Model
Rated Current (A)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
A002 to A009 2011 10.6 10.6 8.9 7.8 6.4
A015 2017 16.7 16.7 14.0 12.2 10.0
A022 2024 24.2 24.2 20.3 17.7 14.5
A028 2031 30.8 30.8 25.9 22.6 18.5
A042 2046 46.2 46.2 38.8 33.9 27.7
A054 2059 59.4 59.4 49.9 43.6 35.6
A068 2075 74.8 74.8 62.8 54.9 44.9
A080 2088 88.0 88.0 73.9 64.5 52.8
A104 2114 114 114 95.8 83.6 68.4
A130 2143 143 143 114.4 95.3 -
