2.9 Knock-Out Hole Dimensions
66 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
2.9 Knock-Out Hole Dimensions
◆ 208 Vac Narrow Models H6BPD002 to D074
480 Vac Narrow Models H6BPB001 to B077
Figure 2.35 Knock-out Dimensions Diagram
Table 2.11 Narrow Bypass Knock-out Hole Dimensions: 208 Vac
Bypass
Model
H6BP
Dimensions
in (mm)
W H D W1 W2 W3 H1 D1 D2 D3 Ød4
D002
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D003
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D004
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D007
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D010
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D016
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D024
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D030
4.18
(106.2)
3.01
(76.5)
2.00
(50.8)
2.25
(57.2)
2.00
(50.8)
1.04
(26.3)
no offset
4.08
(103.5)
3.08
(78.1)
1.51
(38.4)
1.375
D046
7.00
(177.8)
3.00
(76.2)
2.25
(57.2)
2.75
(69.9)
3.32
(84.2)
1.19
(30.3)
no offset
7.00
(177.8)
3.33
(84.5)
0.33
(8.3)
1.750
D059
7.00
(177.8)
3.00
(76.2)
2.25
(57.2)
2.75
(69.9)
3.32
(84.2)
1.19
(30.3)
no offset
7.00
(177.8)
3.33
(84.5)
0.33
(8.3)
1.750
D074
9.75
(247.7)
3.75
(95.3)
2.75
(69.9)
4.00
(101.6)
3.93
(99.9)
1.06
(26.8)
0.50
(12.7)
14.26
(362.3)
3.88
(98.4)
0.38
(9.5)
2.469
