YASKAWA HV600 User Manual

5.8 L: Protection Functions
346 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
• Output current is a minimum of 100% of the drive rated current and the frequency reference is less than 6 Hz.
• Output current is a minimum of 109% of the drive rated current and the frequency reference is 7 Hz or more.
When the drive switches the carrier frequency to the set value, it uses a hysteresis of 12%.
3 : Enable at Overload
The drive decreases the carrier frequency at one of these conditions:
• Output frequency is less than 6 Hz and output current is more than 120%
• Output frequency is 7 Hz or more and the IGBT temperature detected by thermistor is high
■ L8-41: High Current Alarm Selection
No.
(Hex.)
Name Description
Default
(Range)
L8-41
(04F2)
High Current Alarm
Selection
Sets the function to cause an HCA [High Current Alarm] when the output current is more than 150%
of the drive rated current.
0
(0, 1)
0 : Disabled
The drive will not detect an HCA.
1 : Enabled
If the output current is more than 150% of the drive rated current, the drive will detect an HCA.
The MFDO terminal set for an alarm [H2-01 to H2-03 = 10] activates.
■ L8-97: Carrier Freq Reduce during OH
No.
(Hex.)
Name Description
Default
(Range)
L8-97
(3104)
Carrier Freq Reduce during
OH
Sets the function to decrease carrier frequency during oH pre-alarm. 0
(0, 1)
0 : Disabled
1 : Enabled
◆ L9: Drive Protection 2
L9 parameters are used to configure the protection function used to detect cooling fan faults.
■ L9-16: FAn1 Detect Time
No.
(Hex.)
Name Description
Default
(Range)
L9-16
(11DC)
Expert
FAn1 Detect Time Sets the detection time for FAn1 [Drive Cooling Fan Fault]. Yaskawa recommends that you do not
change this parameter value.
4.0 s
(0.0 - 30.0 s)
