3.3 Main Circuit Wiring
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 87
Table 3.10 Output and Control Wiring
Model
H6BP
Motor Wiring
Standard Motor
Terminal Block TB1
Ground Wiring Control Wiring
AWG,
kcmil
Tightening
Torque
(in lb)
AWG, kcmil
Tightening
Torque
(in lb)
A1
Terminal Blocks
TB1, TB3-TB6
A1
Terminal Block
TB2 (FE)
A2
Terminal Blocks
TB1-TB4 and TB6
Panel
Terminal Block
TB4
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
AWG,
kcmil
Tightening
Torque
(in lb)
B001 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B002 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B003 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B004 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B007 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B011 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B014 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B021 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B027 14-2 32
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B034 14-2 32
14-10, 8, 6-4,
or 2-1/0
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B040 14-2 32
14-10, 8, 6-4,
or 2-1/0
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B052 14-2 32
14-10, 8, 6-4,
or 2-1/0
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B065 14-2 32
14-10, 8, 6-4,
or 2-1/0
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B077 6-2/0 120
14-10, 8, 6-4,
or 2-1/0
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26-14 4 26-10 5.3 to 7.1
B096
14 - 8 or
6 - 2/0
50 or 120
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
B124
(1-2) x
(6) or (4)
or (3 - 4/
0)
(1-2) x 80
or 100 or
150
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
B156
6 - 350
kcmil
275
14-10, 8, 6-4,
or 2
35, 40, 45, or
50
24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
B180
6 - 350
kcmil
275 14 - 2/0 120 24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
B240
(1-2) x (4
- 500
kcmil)
(1-2) x 500 14 - 2/0 120 24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
B302
(1-2) x (4
- 500
kcmil)
(1-2) x 500 14 - 2/0 120 24-16 4.4 to 5.3 24-18
*1
8.85 to
10.62
26 - 14 4 26-10 5.3 to 7.1
*1 24-16 is acceptable for solid wire or ferrule use only.
◆ Main Circuit Terminal and Motor Wiring
This section outlines the various steps, precautions, and checkpoints to wire the main circuit terminals and motor
terminals.
WARNING! Fire Hazard. Do not connect main power supply wiring to motor terminals U/T1, V/T2, and W/T3. Connect main power
supply wiring to main circuit input terminals R/L1, S/L2, and T/L3. Incorrect wiring can cause serious injury or death from fire.
