ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU ,QWURGXFWLRQ
1-72 3BSE 002 415R701 Rev A
The FCI provides 24V d.c. (from the source) and an isolated 5V d.c. power to the base cluster’s
I/O modules (12 maximum) by way of the ModuleBus connections. There are three types of FCIs
one for single Advant Fieldbus 100 configurations, one for redundant Advant Fieldbus 100
configurations and one for single PROFIBUS configurations. The power source can be the
SD811/812 power supplies, battery, or other IEC664 Installation Category II power sources.
Power status inputs, 2 x 24 V, to monitor 1:1 redundant mains are also provided.
The single Advant Fieldbus 100 FCI module have two connectors and built-in modems, for
redundant AF 100 twisted pair cables, a connector for the Modulebus Optical port module and a
galvanically isolated RS-232 service port to allow trouble free tools connection.
The redundant Advant Fieldbus 100 FCI module have one connector and built-in modem, for one
AF 100 twisted pair cable and connectors to a connection unit. Two redundant FCI modules are
connecting to each other via an Interconnection Unit (TB815). Connectors for electrical
Modulebus, Modulebus Optical port module and two galvanically isolated RS-232 service ports
are placed on the Interconnection Unit TB815 one for each FCI.
The AF 100 connector plugs can be inserted/removed without interrupting AF 100
communication between other stations.
The single PROFIBUS FCI module have one connector and built-in modems, for PROFIBUS
twisted pair cables, a connector for the Modulebus Optical port module and galvanically isolated
RS-232 service port to allow trouble free tools connection.
The front plate of the FCI modules provides LEDs for diagnostic and status indications.
Two rotary switches are provided for setting of the station address. No other addresses are
required to be set within the I/O-station. Labels for optional user text and item number are also
provide.
,2,QWHUIDFHV
A range of I/O modules is available covering analog, pulse and digital signals of various types.
Interfaces for RTDs and TCs of various types and modules with intrinsically safe interface and
HART communication are available.
The S800 system provides I/O modules with typically 2, 4, 8 or 16 channels depending on type
and ratings of the individual module.
7DEOH  &RPPXQLFDWLRQ,QWHUIDFH0RGXOH
0RGXOHW\SH 'HVFULSWLRQ
CI810A AF 100 Fieldbus Communication Interface, 2 x AF 100 Modems for
twisted pair cable. Power supply 24 V.
Rated isolation voltage 50 V.
CI820 AF 100 Fieldbus Communication Interface for redundant configurations,
1x AF 100 Modems for twisted pair cable. Power supply 24 V.
Rated isolation voltage 50 V.
TB815 Interconnection Unit for redundant FCI (CI820).
CI830 PROFIBUS Fieldbus Communication Interface, one Modems for twisted
pair cable. Power supply 24 V. Rated isolation voltage 50 V.
