ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ *HQHUDO6\VWHP8WL OLWLHV
3BSE 002 415R701 Rev A 1-27
 3URJUDP0RGXOH&RQWHQWV
The program function library, among others, contains PC elements and functional units.
A functional unit is a package of different program functions such as PC elements and
operator’s functions. This simplifies the realization of combined functions with both the control
function and associated operator’s handling via a display screen and keyboard.
Please find below a survey of the functional contents and the concrete PC elements and
functional units in the different program modules.
%DVLF6\VWHP4&%$6
The basic system program is sufficient when you need digital signal processing, arithmetic,
queue and shift functions. It works with both analog and digital input and output signals.
)XQFWLRQDO6HUYH
• Logic and time delays
• Sequence control
• Data and text handling
• Calendar time functions
• Arithmetic
• Positioning
• Fast pulse counting and frequency measurement
•Reports
• Functional units, binary
1
• Functional units, analog
1
• Functional units, motor and valve control, group start
1
• Table handling
• EXCOM Data Set communication
• Support for MasterBus 300
• Support for GCOM
• Support for RCOM
• Support for MultiVendor Interface
• Support for connection to Advant Fieldbus 100
• Support for PROFIBUS-DP
• Support for LONWORKS Network
• Support for connection to ACV 700 and DCV 700 thyristor converters
• Support for connection to TYRAK and SAMI thyristor converters
• Support for connection to strain gauge scales
• Free-programmable module.
1. Only the PC and data base element parts of the functional units are included in the basic program module.
For presentation and dialog support, QC07-OPF41 must be added. Special dedicated interface boards are
QRW
included in the basic unit.
