ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix B RM500 Cabinet - Data Sheet
B-2 3BSE 002 415R701 Rev A
B.2 Dimensions and Weight
The dimension and weight of the RM500 cabinets are given in Table B-1.
Table B-1. RM500 Cabinet Measurements
Characteristics
Cabinet Type
RM500V1
Height = 1925 mm
(75.8 inch.)
RM500V1
Height = 2125 mm
(83.7 inch.)
RM500V2
Height = 2225 mm
(87.6 inch)
Dimensions
Cabinet
(1)
WxDxH
(1) The dimensions includes door and rear plate.
800x512x1925 mm
(31.5x20.2x75.8 inch.)
800x512x2125 mm
(31.5x20.2x83.7 inch.)
700x637x2225 mm
(27.6x25.1x87.6 inch.)
End Panel
(2)
W1xD1
(2) W1xD1 shows the dimension for a single end panel. When mounting two end panels to a cabinet add 2x20 mm at the cabinet width, W
but use D1 as cabinet depth.
20x530 mm
(0.8x20.9 inch.)
20x530 mm
(0.8x20.9 inch.)
20x655 mm
(0.8x25.8 inch.)
Cable Entry W2xD2 660x311 mm
(26.0x12.2 inch.)
660x311 mm
(26.0x12.2 inch.)
560x436 mm
(22.0x17.2 inch.)
Weight
(3)
(3) The weight does not include equipment to be installed within the cabinet.
150-200 kg
(330-440 lbs)
150-200 kg
(330-440 lbs)
150-200 kg
(330-440 lbs)
Doors Single/Double Single/Double Single
Mounting Planes 19”/24” 19”/24” 19”
U-Modules
(4)
Cabinet/Hinged Frame
(4) U-Modules, see Appendix D, Item Designations.
39U/37U 43U/41U 45U/43U
Swing Radius
(5)
(5) The space required for door(s) and the hinged frame. See Figure B-3.
Single Door (SD) 793 mm (31.2 inch.) 793 mm (31.2 inch) 693 mm (27.3 inch.)
Double Door (DD) 415 mm (16.3 inch.) 415 mm (16.3 inch.) -
Subrack (S100 I/O) in Hinged Frame
(SR)
600 mm (23.6 inch.) 600 mm (23.6 inch.) 600 mm (23.6 inch.)
