&KDSWHU ,QWURGXFWLRQ
1-78 3BSE 002 415R701 Rev A
3RZHU6XSSOLHV
The power supplies SD811 and SD812 (24 V output) can be used to power processor modules
and S800 I/O modules, through the processor unit and to power 24 V field circuits (optional).
The supplies have a wide input voltage range, nominally 110V-240 V without input voltage range
selection. The primary side can connect to industrial mains installation class III (IEC664).
The outputs are short circuit proof and can operate with resistive, capacitive and constant power
loads, for example, switched mode power converters.
The outputs of the supplies can be connected in parallel to increase power, 2 x SD811 or
2 x SD812, or be configured for redundant mains to increase availability, 2 x SD811 or
2 x SD812. Each supply has a power OK signal which can connect to the SA or SB inputs of the
communication interface modules or Optical Modulebus modem to monitor power status in 1:1
redundant mains configurations.
TU836 Extended MTU, 120 mm wide. Two isolated groups with one row
of 4 uncommitted terminals individually fused (3 A), one row of 4
uncommitted terminals, 2 pcs L and 2 pcs N- terminals.
Rated isolation voltage 250 V.
Conductor area: 0.2-2.5 mm
2
, AWG 24-12.
TU837 Extended MTU, 120 mm wide. 16 individually isolated terminals
(8 ch) each channel has one process voltage terminal and one
fused (3 A) load outlet.
Two groups of uncommitted return terminals.
2 + 3 interconnected terminals.
Rated isolation voltage 250 V.
Conductor area (ch): 0.2-4 mm
2
, AWG 24-10.
Conductor area (return): 0.2-2.5 mm
2
, AWG 24-12.
TU838 Extended MTU, 120 mm wide. Two isolated groups. Each group
8 I/O channels, 4 fused transducer power outlets, 4 return con-
nections and process power connection.
Rated isolation voltage 50 V.
Conductor area: 0.2-2.5 mm
2
, (Stranded) AWG 24-12.
TU890 Compact MTU, 58 mm wide for modules with Intrinsically safe
interface. 27 uncommitted terminals and 4 terminals for power
supply.
Rated isolation voltage 50 V.
Conductor area: 0.2-2.5 mm
2
, (Stranded) AWG 24-12.
7DEOH 60RGXOH7HUPLQDWLRQ8QLWV
0RGXOHW\SH 'HVFULSWLRQ
