Appendix D Item Designations
D-10 3BSE 002 415R701 Rev A
D.8 Examples of Item Designation in Cabinets
A number of modules, connection points, and so on, located in a double cabinet are illustrated in
Figure D-17.
An extract from a wiring table, Table D-1, shows the corresponding item designations,
Figure D-17. Example of general Disposition of a Double Cabinet
