ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix E Current Consumption and Heat Dissipation
E-2 3BSE 002 415R701 Rev A
Table E-1. Current Consumption and Power Dissipation, Controller Modules
Type
Designation
Current Consump. (A)
Tot. Power
Dissipation (W)
Comments
No of
Boards
Total
I
tot
, P
tot
5 V 24 V
CI522A 0.6 - 3.3
CI531 0.4 0.04 3
CI532Vxx 0.4 0.04 3
CI534Vxx 0.4 0.04 3
CI535 0.4 0.04 3
CI538 0.4 0.04 3
CI541V1 0.85 0.25 11
CI543 0.6 0.25 9
(1)
(1) 6 W dissipated in the transceiver connected to the module.
CI570 0.9 - 5
CI572 0.35 - 1.75
CI573 0.35 - 1.75
CS513 0.25 0.25 8
MB510 0.01 0.05
PM511 4.9 0.2 25
PU535 0.4 0.04 3
SB510 - - 20 Approx.
SB511 - - 20 Approx.
SC510 1.3 0.006 0.7
SC520 1.5 0.006 0.8
SR511 - - 100 Approx.
(2)
(2) Do not include redundant power supply units in the calculation of number of boards/units.
TC520 0.05 - 0.25
Sum
