Advant
®
Controller 450 User’s Guide
Section H.1 Example of Halt Code Printout
3BSE 002 415R701 Rev A H-1
Appendix H Halt Codes
H.1 Example of Halt Code Printout
You can obtain the result of the command LSYSHI as a printout on the printer with the
command HARDCOPY in accordance with Figure H-1.
H.2 List of Halt Codes and Corrective Actions
Typical halt codes which can be read with the command LSYSHI and corrective measures are
listed in this section. Further fault finding and user repair is described in Chapter 5,
Maintenance.
DANGER
You should carefully follow general safety instructions given in Chapter 5,
Maintenance when fault finding and operating an Advant Controller system
to minimize the risk of injury to personnel and damage to the equipment.
Figure H-1. Example of LSYSHI Printout
‘*LSYSHI
QC02-BAS21 *7.0/0 *02/01/01
COPYRIGHT 1994 BY ABB INDUSTRIAL SYSTEMS AB
CXNLIB7.0/0
CXKLIB *7.0/0
Network, node :11,1
Time, date : 10:10:15, 1994-12-24
Current task :CXKK 340 H’00482360
SSP H’004800DA
D0 H’00000069 D1 H’00000834 D2 H’004A00DC D3 H’0000FFFF
D4 H’00000172 D5 H’000003E5 D6 H’00002544 D7 H’000182D8
AO H’00480128 A1 H’00480128 A2 H’0048545E A3 H’0001C9F6
A4 H’00052886 A5 H’0048246E A6 H’00480100 A7 H’0048246A
H’004800DA H’2704
H’004800E2 H’0165
H’004800EA H’2400
H’004800F2 H’246E
H’004800FA H’0000
System stack
H’0000
H’C20A
H’0000
H’0048
H’760A
H’5244
H’FFFC
H’ODEE
H’0100
H’0070
H’002C
H’3A79
H’0048
H’0000
System halt code = 05
Bus time-out error in system or kernel mode
