ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Section 2.2.14 Engineering Station
3BSE 002 415R701 Rev A 2-43
2.2.14 Engineering Station
The following apply to an engineering station type Advant Station 100 Series ES when
connected directly to the Advant Controller 450.
Electric Installation (including Power Supply)
Plug the communication cable enclosed with the engineering station into the X10 SERVICE
connector on the processor module front.
From the viewpoint of the Advant Controller, there are no restrictions on the mains power
supply of the engineering station, for example no requirement of earthing and same supply.
The controller and the engineering station are galvanically isolated from each other by the
communication interface.
2.2.15 Checklists
In the setup instructions, you are occasionally referred to a separate document,
Interference-free Electronics Design and Applications.
The following checklist is a summary of important information addressed to the actual
Advant Controller 450.
2.2.15.1 Grounding Philosophy, Earthing Line System
Table 2-5. Grounding Philosophy, Earthing Line System
Item Concerning Action
Grounding philosophy Ground system Grounding only to power earth line network.
Only one ground system. No exceptions.
Earth line system Design The earth line system of the installation must be
carefully installed and must incorporate the
switchgear.
