ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ &RPPXQLFDWL RQ
3BSE 002 415R701 Rev A 1-91
([SODQDWLRQV
Mainly recipe data and report data are sent.
Configuration data transfer.
 The control of d.c. motors in a drive system is integrated in the converter, which involves a
considerable exchange of signals with Advant Controller 450. A special communication
package implemented in the converter makes this adaptation possible.
EXCOM also provides reading of object data of the type AI, AO, DI, DO (Analog
Input/Output, Digital Input/Output). This is utilized by the given product.
 The main use of a printer for generating reports is described in Section 1.7.8.3, Control
Functions, under the heading Reports.
 Read/write process I/O data.
5, % indicates Real, Integer and Boolean data, respectively. Bi-directional information flow is
possible.
(indicates handling of time-stamped events. Events are defined and time-stamped in the central
I/O of Advant Controller 450 or in distributed units of the type Advant Controller 110 and
Advant Controller 70. Advant Controller 450 sends the information to operator stations for
presentation in lists. High accuracy in time.
($ also indicates handling of time-stamped events. Events originated in certain distributed
units are time-stamped in the Advant Controller 450. Time delay due to communication must be
reflected. When Data Set is used a supporting application program is needed in the Advant
Controller 450. Advant Controller sends the information to operator station for presentation in
lists. Less accuracy in time.
6indicates subscription of data from the Advant Controller 450 data base. It is requested by an
operator station or a similar station. A subscription is normally an object-oriented, complex
package of mixed data used for presentation purposes.
&indicates command signals, for example complex commands including several parameters or
increase/decrease, start/stop, and so on from an operator station or similar device.
Advant Controller 70 Advant Fieldbus 100 R I B E
ABB Active Mimic Controller RCOM B
Other manufacturers’ equipment MVI R I B
PROFIBUS-DP R I B
LONWORKS Network R I B E
7DEOH &RPPXQLFDWLRQ6XUYH\&RQWLQXHG
(TXLSPHQW 8VHGOLQNV )XQFWLRQDOLW\(explanations below)
