ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ &RPPXQLFDWL RQ
3BSE 002 415R701 Rev A 1-81
*&202XWOLQH'HVFULSWLRQ
GCOM is a data link protocol used for data exchange with the help of message passing between
external computers and Advant OCS stations/controllers. The protocol is available for VAX
computers. The following data link protocol alternatives are supported:
• IEEE 802.2 class 1 logical link control and IEEE 802.3 CSMA/CD medium access control
• CCITT recommendation X.25.2 LAPB with transmission rate 19.2 or 50 kbits/sec
• ADLP-10 (ABB Data Link Protocol), an asynchronous protocol based on ECMA 16 and
ECMA 24, with transmission rate of 9.6 kbits/sec.
You can duplicate GCOM to achieve full redundancy.
%XV([WHQVLRQWR6,2
The processor module and optional communication boards are located in a controller subrack.
This cannot accommodate any process I/O. One way you can connect such I/O is to use I/O
subracks. With an electrical bus extension the I/O subracks can be located close to the controller
subrack.
For increased availability, you can duplicate CPUs, bus extension and cables.
Figure 1-31 illustrates a bus extension comprising two I/O subracks.
)LJXUH ([DPSOHRI(OHFWULFDO5HGXQGDQW%XV([WHQVLRQ
I/O subrack 1
I/O subrack 2
Controller subrack
Total length of bus extension
cable is max 12 m (39 ft).
D
S
B
C
1
7
4
D
S
B
C
1
7
4
P
M
1
1
5
P
M
1
1
5
D
S
B
C
1
7
4
D
S
B
C
1
7
4
For redundant S100 I/O bus
duplicate CPUs, bus extenders
and cables.
The I/O bus connected to the
left CPU should be connected
to the left bus extender and
vice versa.
