Advant
®
Controller 450 User’s Guide
Chapter 2 Installation
2-42 3BSE 002 415R701 Rev A
Functional Measures, General
The following instructions apply.
Communication module CI531: No measures needed.
Modem: X
ON
/ X
OFF
protocol utilized and the factory settings of the modem TC562 or
DSTC X008 (jumpering) are adequate. If a.c. 230 V is not desired, please reconnect to
a.c. 120 V. Instructions are enclosed with the modem.
Printer: Set the printer to meet the requirements stated in Table 2-4.
Preparation for Start-up
Check that the printer and any modem are adapted to the mains voltage at hand.
2.2.13 Communication
Please refer to the following separate documentation:
• The user’s guide for the actual communication link.
• Assembly drawings, terminal diagram forms, and so on, enclosed at delivery of the
Advant Controller. These show you the location of the hardware.
The following instructions apply:
• Cable routing in cabinets, see Section 2.2.6, Cable Routing in Cabinets.
• Grounding of cable shields, see Section 2.2.5, Grounding.
Regarding cable selection, external cable routing, and so on, see general information in
Interference-free Electronics Design and Applications.
A carefully accomplished electric installation is the basis of future interference-free operation.
Table 2-4. Printer Settings
Data Value
Character code Standard 7 bits ASCII
Parity None
Number of stop bits 1
Data word length 8 bits
Type of interface RS-232-C
Baud rate 9600 bits/s
Protocol X
ON
/X
OFF
No. of characters
per line
72
Printer speed 160 characters/s
