ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
6HFWLRQ 3URFHVV,QWHUIDFH
3BSE 002 415R701 Rev A 1-63
$QDORJ2XWSXW0DLQ3RLQWV
• Analog outputs are available for standard voltage and current signals.
• There are both isolated and non-isolated outputs.
• Optional redundancy is featured, where one type of board can be duplicated to achieve
increased availability.
• A board is offered which combines analog inputs and analog outputs (loop dedicated I/O).
• An output is read out each time new values are entered into the data base.
• Optional software limitations can be selected.
$QDORJ2XWSXW%RDUG7\SHV
Table 1-16 presents available analog output boards.
7DEOH $QDORJ2XWSXW%RDUGV
%RDUGW\SH 'HVFULSWLRQ &RQQHFWLRQXQLW &DEOH
DSAO 110 Four channels, resolution 12 bits incl. sign,
0 to ±10 V or
0 to ±20 mA, 0 to ±10 mA,
4 to 20 mA (elevated zero obtained by SW)
galvanic isolation, channel by channel
DSTA 160 DSTK 223L3
DSAO 120 Eight channels, resolution 12 bits incl. sign,
0 to ±10 V or
0 to ±20 mA
4 to 20 mA (elevated zero obtained by SW)
DSTA 170 DSTK 223L3
DSAO 120A Eight channels, resolution 12 bits incl. sign,
0 to ±10 V or
0 to ±20 mA
4 to 20 mA (elevated zero obtained by SW)
DSTA 171 DSTK 223L3
DSAO 130 16 channels, resolution 8 bits unipolar
0 to + 10 V or
0 to + 20 mA, 0 to + 10 mA
4 to 20 mA (elevated zero obtained by SW)
DSTA 180 DSTK 221L3
DSAO 130A 16 channels, resolution 8 bits unipolar
0 to + 10 V or
0 to + 20 mA, 0 to + 10 mA
4 to 20 mA (elevated zero obtained by SW)
DSTA 181 DSTK 221L3
DSAO 130 16 channels, resolution 8 bits unipolar
0 to + 10 V or
0 to + 20 mA, 0 to + 10 mA
4 to 20 mA (elevated zero obtained by SW)
DSTA 137 provides
object oriented con-
nection to DSAI 130
and DSAO 130
DSTK 150
