Section 2.2.16 Final Procedures Before Start-up
3BSE 002 415R701 Rev A 2-49
2.2.15.9 Miscellaneous
2.2.16 Final Procedures Before Start-up
Remove all debris remaining from the work performed and clean off all grease and dirt.
Check that no tools or assembly materials are left in the cabinets. Vacuum-clean the cabinets.
2.3 Shut-down Procedures
Before power supply switch-on and start-up of the equipment, it is important that you know how
to shut down in different situations.
Necessary Outfit
No special kit needed.
2.3.1 Safety Regulations
The instructions given in Section 2.2.1, Safety Regulations are applicable in all situations when
you work with an Advant Controller and associated equipment. Please read the instructions
carefully. One instruction is highlighted:
DANGER
Work with care when supply voltage is applied in the system. The voltage in
the cabinet can cause injury and can even kill a human being.
Table 2-12. Miscellaneous
Item Concerning Action
Relays and contactors
in cabinets
Suppression Cabling to non-suppressed inductive loads in
Advant OCS cabinets must be kept more
than 100 mm away from internal cables.
Thermo-couples Supply connection
Position of “CJC”
(compensation unit for
cold junction
DSTA 155/155P)
Power supply for compensation of cold junc-
tion on DSTA 155/155P is taken from the
cabinet.
DSTA 155/155P must be placed as close to
the object as possible. Located in the cabinet
only if original (old) cabling is to be used.
Analog inputs/outputs Type Correct type: For grounded transmitters/
actuators/loads the inputs/outputs must be
differential or isolated.
