Allen-Bradley SmartGuard 600 User Manual

Publication 1752-UM001A-EN-P - October 2006
Function Blocks Command Reference 181
Muting Function Block Parameters
Set these parameters for the two-hand control function block.
Muting Function Block Parameters
Parameter Settings/Range Default
Muting Mode • Parallel muting with 2 sensors
This pattern is suitable for applications at a conveyor entrance. Use this pattern when
two retro-reflective photoelectric sensors are set up as muting sensors with intersecting
detection zones.
• Sequential muting (forward direction)
This pattern is suitable for applications at a conveyor entrance. Use this pattern when
four through-beam photoelectric sensors are set up as muting sensors.
• Sequential muting (both directions)
This pattern is suitable for applications at a conveyor entrance or exit. Use this pattern
when four through-beam photoelectric sensors are set up as muting sensors.
• Position detection
This pattern is suitable for applications in which muting is controlled by a switch input.
Use this pattern to temporarily disable the light-interruption signal of the light curtain
when an operator is placing an object in the machine opening, and the machine is in a
state where it will not harm the operator (hazards are in a different zone of the machine).
In all of these setting explanations, the muting sensors are on when detection is performed
and off when detection is not performed.
Parallel muting with
2 sensors
Synchronization
Time
(1)
30 ms…3 seconds in 10 ms increments.
The timer SV must be longer than the controller’s cycle time.
3 seconds
Input Type of AOPD • Dual Channel Equivalent (NC/NC)
• Dual Channel Complementary (NC/NO)
Dual Channel
Equivalent
Discrepancy Time
(AOPD)
10…500 ms in 10 ms increments
(2)
The timer SV must be longer than the controller’s cycle time.
30 ms
Input Type of
Override Signal
• Single Channel
• Dual Channel Equivalent (NO/NO)
• Dual Channel Complementary (NC/NO)
• Not Used
Not used
Discrepancy Time
(Override)
10…500 ms in 10 ms increments
(2)
The timer SV must be longer than the controller’s cycle time.
30 ms
Max Muting Time 500 ms…127.5 seconds in 500 ms increments
0…500 ms in 10 ms increments
60 seconds
Max Override Time 500 ms…127.5 seconds in 500 ms increments 60 seconds
(1) between Muting Signal 11 and Muting Signal 12 or between Muting Signal 21 and Muting Signal 22
(2) A discrepancy time check will not be performed is 0 is set.
