Allen-Bradley SmartGuard 600 User Manual

Publication 1752-UM001A-EN-P - October 2006
212 Explicit Messages
• Response data to explicit messages cannot be used in a
SmartGuard controller’s use program.
Access Controller
Parameters Using
DeviceNet Explicit
Messages
You can read and write to controller parameters by sending DeviceNet
explicit messages to the SmartGuard controller. The controller
processes the received messages and returns a response. The
messages described in these tables are supported by the SmartGuard
controller.
ATTENTION
The data attributes handled by standard I/O communications
and explicit message communications are non-safety data. The
necessary measures for safety data are not taken during
generation of standard or explicit message data. Do not use
this data to operate a safety control system.
Reading General Status
Explicit Message Service Function
Command
Response
Service
Code
Class ID
Hex
Instance ID
Hex
Attribute
ID
Data
Size
Read Unit General
Status
Read Reads the controller’s
general status
OE hex 39 hex 01 hex 6E hex -- 1 byte
Reading I/O Area
Explicit Message Service Function
Command
Response
Service
Code
Class ID Instance ID Attribute
ID
Data
Size
Read I/O Area Read Reads the controller’s
I/O data
Address Specification
Range:
• Local Input = 0 or 1
• Local Output/Test
Output = 0 or 1
• Safety Input =
0…511
• Safety Output =
0…511
OE hex 356 hex • Local Input = 01
hex
• Local
Output/Test
Output = 02 hex
• Safety Input =
05 hex
• Safety Output =
06 hex
6E hex -- Read data
