TX100 S3 Upgrade and Maintenance Manual 181
Expansion cards and backup units
Figure 103: Removing the BBU holder from the chassis
Ê Press the release lever to disengage the BBU holder (1).
Ê Slide up the BBU holder and take it out of the chassis (2).
9.3.3.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the cable clamps.
Ê Close the side cover as described in section "Installing the side cover" on
page 58.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 59.
/
