280 Upgrade and Maintenance Manual TX100 S3
Front panel and external connectors
13.2 Replacing the front USB module
13.2.1 Required tools
● Preliminary and concluding steps:
– Phillips PH2 / (+) No. 2 screw driver
● Replacing the front panel module:
– Phillips PH2 / (+) No. 2 screw driver
13.2.2 Preliminary steps
Before replacing the front USB module, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 69.
Ê Shut down the server as described in section "Shutting down the server" on
page 42.
Ê Remove the AC power cord from the cable tie and disconnect it from the
system as described in section "Disconnecting power cord" on page 43.
Ê Bring the server to its horizontal position.
Ê Open the side cover as described in section "Removing the side cover" on
page 45.
Ê Remove all accessible drives as described in section "Removing accessible
drives" on page 257.
Ê Remove the front cover as described in section "Removing the front cover"
on page 51.
Ê Remove the HDD cage as described in section "Removing the HDD cage"
on page 61.
Field Replaceable Units (FRU)
Average task duration: 15 minutes
