TX100 S3 Upgrade and Maintenance Manual 347
Appendix
Buttons
16.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Button Function
On / Off button
This button is used to switch the server on or off.
I If the system is running an ACPI-compliant operating
system, pressing the On / Off button will performs a
graceful shutdown.
Field Replaceable Units (FRU)
Component Notes
System board no TPM or expansion cards installed
CPU with CPU heat sink
CPU fan
1 memory module installed in DIMM slot 1A
Power supply unit
system fan 1
system fan 2
Table 8: Minimum startup configuration - components
