Fujitsu PRIMERGY TX100 S3 Maintenance Manual

268 Upgrade and Maintenance Manual TX100 S3
Accessible drives
12.4.4 Replacing a slimline optical disk drive (ODD)
Ê Remove the slide-in unit as described in section "Removing a slimline
optical disk drive (ODD)" on page 260.
Figure 179: Removing the fixation plate from the slide-in unit
Ê Remove the fixation plate from the left side of the slide-in unit.
Figure 180: Removing the slimline ODD from the slide-in unit (A)
Ê Remove the two M2 x 2.5 mm screws from the left side of the slide-in unit.
