TX100 S3
Upgrade and Maintenance Manual
329
Cabling
15.2
Replacing the power cable
Figure 227: Power
cable T26139-Y4012-V
101
Field Replaceable Unit
s (FRU)
A
verage task duration: 10 minutes
Connect
or
Used for
P1
POWER SA
T
A on the system board
P2
HDD 4
P3
HDD 3
P4
HDD 1
P5
HDD 2
P6
not used
P7
optical drive (top)
P8
optical drive (bottom)
P6
P5
P4
P1
P7
P8
P3
P2
328
330
