208 Upgrade and Maintenance Manual TX100 S3
Main memory
10.3.3 Removing a memory module
Ê Identify the desired memory slot according to the mounting order described
in section "Memory sequence" on page 202.
V CAUTION!
Ensure to maintain an operational configuration when removing
memory modules. For additional information, please refer to section
"Operation modes" on page 203.
Figure 125: Removing memory modules
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory module connector (1).
Ê Remove the ejected memory module (2).
10.3.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the side cover as described in section "Installing the side cover" on
page 58.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 59.
Ê If available, update the system board BIOS to the latest version as described
in section "Updating the system board BIOS" on page 73.
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task, re-enable BitLocker as described in section "Enabling
BitLocker functionality" on page 82.
/
/
