Fujitsu PRIMERGY TX100 S3 Maintenance Manual

258 Upgrade and Maintenance Manual TX100 S3
Accessible drives
12.3.3 Removing an optical disk drive (ODD)
Figure 169: Connecting cables to the optical disk drive
Ê Disconnect all cables from the optical disk drive (see figure 227 on
page 329).
1 Power cable connector P8
2 SATA cable
/
0
