ftp> get HP_StorageWorks_MPX200_FRU.bin
200 PORT command successful.
150 Opening BINARY mode data connection for 'HP_StorageWorks_MPX200_FRU.bin'
(6168 bytes).
226 Transfer complete.
ftp: 6168 bytes received in 0.00Seconds 6168000.00Kbytes/sec.
ftp> quit
221 Goodbye.
Restoring router configuration and persistent data
1. Transfer the saved data from a workstation to the router by executing an FTP utility on the
workstation.
The following example shows an FTP transfer to put previously saved router configuration data
on the router:
c:\> ftp 172.17.137.102
Connected to 172.17.137.102.
220 (none) FTP server (GNU inetutils 1.4.2) ready.
User (172.17.137.102:(none)): ftp
331 Guest login ok, type your name as password.
Password: ftp
230 Guest login ok, access restrictions apply.
ftp> bin
NOTE:
Dual-blade MPX200s perform an automatic field-replaceable unit (FRU) restore on a new blade
any time it is detected in the chassis.
200 Type set to I.
ftp> put HP StorageWorks MPX200_FRU.bin
200 PORT command successful.
150 Opening BINARY mode data connection for 'HP StorageWorks MPX200_FRU.bin'.
226 Transfer complete.
ftp: 6168 bytes sent in 0.00Seconds 6168000.00Kbytes/sec.
ftp> quit
221 Goodbye.
2. Update a blade with the saved configuration data by executing the fru restore CLI command.
The fru restore command has the following two options:
• Full restore restores all router configuration parameters, including IP addresses, subnet masks,
gateways, VPG settings, LUN mappings, and all other persistent data.
• Partial restore restores only the LUN mappings and persistent data, such as discovered FC
targets and iSCSI initiators.
Command Line Interface usageCLI usage310
