4. Enter the following command:
MPX200 (admin) #> fru save
FRU save completed. Configuration File is HP_Storage-
Works_MPX200_FRU.bin. Please use FTP to extract the file out from the
System.
MPX200 (admin) #>
NOTE:
The FRU save creates a bin file containing the router’s persistent data, configuration, and
LUN mappings. The file is stored in the routers /var/ftp directory. You must then FTP the
tar file from the router.
5. Establish an FTP connection to the MPX200 management port and log in:
Username: ftp
Password: ftp
6. Enter the following command to set the FTP transfer type to Binary:
ftp> bin
7. Enter the following command to access the HP_StorageWorks_MPX200_FRU.bin file:
ftp> get HP_StorageWorks_MPX200_FRU.bin
Restoring the MPX200 configuration
There are two options for restoring configurations on the MPX200:
• Full Configuration Restore, which fully restores the router’s configuration (all configuration para-
meters and LUN mappings)
• Partial Restore (Mappings), which restores only the LUN mappings
The restored configuration takes effect after the router is rebooted.
Restoring the configuration using the MPX200 CLI
1. Establish an FTP connection to the MPX200 management port and log in:
Username: ftp
Password: ftp
2. Enter the following command to set the FTP transfer type to binary:
ftp> bin
3. Enter the following command to put the HP_StorageWorks_MPX200_FRU.bin file:
ftp> put HP_StorageWorks_MPX200_FRU.bin
4. Log in to the MPX200 using a Telnet session to the management port or console port:
Username: guest
Password: password
5. Enter the following command:
MPX200> admin start
6. Enter config as the password.
Saving and restoring the MPX200 configuration366
