5. Route the power cord:
a. Starting from the front of the rack, connect the power cord to the MPX200.
b. For the left blade, the cord by following the gap between the chassis and the chassis rail
(Figure 13).
c. Repeat for the right blade.
NOTE:
The right blade requires the power cord to extend approximately 12 in. (30 cm) beyond
the front edge, due to the positioning of the socket on the PCM.
1. Power cord
Figure 13 Power cord
.
MPX200 Multifunction Router 35
