6-6 Range, Digits, Speed, and Filters Models 2500 and 2502 User’s Manual
Setting speed
Speed is set from the SPEED ACCURACY MENU and is structured as follows. Use
Section 1, “Rules to navigate menus,” to check and/or change the speed setting.
SPEED-ACCURACY MENU
Press SPEED or CONFIG SPEED to display the menu (Figure 6-1).
• FAST — Sets speed to 0.01 PLC and sets display resolution to 3½ digits.
• MED — Sets speed to 0.10 PLC and sets display resolution to 4½ digits.
• NORMAL — Sets speed to 1.00 PLC and sets display resolution to 5½ digits.
• HI ACCURACY — Sets speed to 10.00 PLC and sets display resolution to 6½ digits.
• OTHER — Use to set speed to any PLC value from 0.01 to 10. Display resolution is
not changed when speed is set with this option.
NOTE The SPEED setting is global and affects both channels. After setting speed, dis-
play resolution for the single-channel display mode can be changed using the
DIGITS key.
Figure 6-1
Speed configuration menu tree
Speed
Normal
(1.00PLC,
5½ Digits)
Fast
(0.01PLC,
3½ Digits)
Med
(0.10PLC,
4½ Digits)
HI Accuracy
(10PLC,
6½ Digits)
Other
(Set Speed
0.01 to 10PLC)
