17-2 SCPI Command Reference Models 2500 and 2502 User’s Manual
Reference tables
Table 17-1 through Table 17-10 summarize the commands for each SCPI subsystem. The
following list includes the SCPI subsystem commands and the table number where each
command is summarized.
General notes:
Brackets ([ ]) are used to denote optional character sets. These optional characters do not
have to be included in the program message. Do not use brackets in the program message.
Angle brackets (< >) are used to indicate parameter type. Do not use angle brackets in the
program message.
The Boolean parameter (<b>) is used to enable or disable an instrument operation. 1 or
ON enables the operation, and 0 or OFF disables the operation.
Upper case characters indicate the short-form version for each command word.
Default Parameter — Listed parameters are both the *RST and :SYSTem:PRESet
defaults, unless noted otherwise. Parameter notes are located at the end of each table.
SCPI — A checkmark (✓) indicates that the command and its parameters are SCPI con-
firmed. An unmarked command indicates that it is a SCPI command, but does not conform
to the SCPI standard set of commands. It is not a recognized command by the SCPI con-
sortium. SCPI confirmed commands that use one or more non-SCPI parameters are
explained by notes.
Summary table Subsystem Function(s)
17-1
17-2
17-3
17-4
17-5
17-6
17-7
17-8
17-9
17-10
CALCulate
DISPlay
FORMat
OUTPut
SENSe
SOURce
STATus
SYSTem
TRACe
TRIGger
Math, REL, ratio, delta, limits, buffer statistics.
Display format and messages.
Remote data format.
Source 1 and source 2 output on-off, output enable.
Channel 1 and channel 2 current measurements.
Channel 1 and channel 2 source configuration.
Instrument status.
System presets, error formats, auto zero, line freq.
Channel 1 and channel 2 buffer control and formats.
Unit triggering control.
