10-16 Triggering Models 2500 and 2502 User’s Manual
• HALT — Use to return the Model 2500 to the idle state. HALT does not turn off the
output. The programmed source level will still be available at the OUTPUT terminals.
The following actions will take the Model 2500 out of idle:
–Turn the output off and then on again.
– Reselect the arm or trigger event.
– Exit from the menu structure, and then reenter it by pressing CONFIG and then
TRIG.
Figure 10-8
Configure trigger menu tree
Config
Trig
Trig
Layer
Trigger
In
Trigger
Out
Count
Arm
Layer
Arm
Out
Line Events
Arm In
Immediate
Trigger
Link
Line Events
Delay Count
Halt
Immediate
GPIB Timer Manual TLINK STEST
STEST STEST
