Model 2500 and 2502 User’s Manual Getting Started 1-29
Table 1-10
Sweep, digits, speed, and data store configuration menus
Configuration menu item Description
CONFIG SWEEP
CONFIGURE SWEEPS
TYPE
NONE
STAIR
LOG
CUSTOM
# POINTS
ADJUST-POINTS
INIT
SWEEP-COUNT
FINITE
INFINITE
SOURCE-RANGING
BEST-FIXED
AUTO-RANGE
FIXED
CONFIG DIGITS
DISPLAY DIGITS
CONFIG SPEED
SPEED-ACCURACY-MENU
FAST
MED
NORMAL
HI ACCURACY
OTHER
CONFIG STORE
STORE TIMESTAMP
ABSOLUTE
DELTA
Configure sweeps.
Select sweep type.
Disable sweep.
Staircase sweep, program START, STOP, STEP.
Log sweep, program START, STOP, # POINTS.
Custom sweep, program parameters.
Program number of sweep points.
Set individual point values.
Set first point value.
Set sweep count.
Program sweep count value.
Never-ending sweep.
Set sweep ranging mode.
Best fixed range based on maximum value.
Auto range during sweep.
Set fixed source range.
Set display number of digits.
Select 3.5, 4.5, 5.5, or 6.5.
Set measurement speed.
Fast speed.
Medium speed.
Normal.
Maximum accuracy.
Program NPLCs (number power line cycles).
Configure data store timestamp.
Absolute timestamp.
Delta timestamp.
