Models 2500 and 2502 User’s Manual Basic Operation 3-7
Front panel source delay
To set the manual source delay from the front panel:
1. Press CONFIG then SRC1 or SRC2.
2. Select DELAY from the displayed choices, then press ENTER.
3. Enter the desired DELAY value, then press ENTER.
4. Press EXIT to return to normal display.
To set the auto source delay state from the front panel:
1. Press CONFIG then SRC1 or SRC2.
2. Select AUTO-DELAY from the displayed choices, then press ENTER.
3. Select ENABLE or DISABLE as desired, then press ENTER.
4. Press EXIT to return to normal display.
NOTE The delay period is the same for both sources. If you change the delay on one
channel, the delay period on the other source will change to the same value.
Remote command source delay
Use the appropriate command shown in Table 3-4 to program the source delay via remote.
(See Section 17 for details.) For example, the following command sets the source delay to
50ms:
:SOUR1:DEL 0.05
Table 3-4
Source delay commands
Command Description
:SOURce[1]:DELay <Delay>
:SOURce[1]:DELay:AUTO <State>
:SOURce2:DELay <Delay>
:SOURce2:DELay:AUTO <State>
Set source delay.
Enable/disable auto delay (ON or OFF).
Set source delay.
Enable/disable auto delay (ON or OFF).
