Engine configurations related to SFOC
The engine type is available in the following ver-
sion only with respect to the efficiency of the tur-
bocharger:
With conventional turbocharger, which is the
basic design and for which the lists of capacities
Section 6.03 are calculated.
For this engine type the optimising point O has to
be equal to the specified MCR point M.
Calculation of List of Capacities and Exhaust Gas Data
Updated engine and capacities data is available
from the CEAS program on www.mandiesel.com
under ‘Marine’ → ‘Low speed’ → ‘CEAS Engine
Room Dimensions’.
This chapter describes the necessary auxiliary ma-
chinery capacities to be used for a nominally rated
engine. The capacities given are valid for seawater
cooling system and central cooling water system,
respectively. For derated engine, i.e. with a speci-
fied MCR and/or optimising point different from the
nominally rated MCR point, the list of capacities
will be different from the nominal capacities.
Furthermore, among others, the exhaust gas data
depends on the ambient temperature conditions.
Based on examples for a derated engine, the way
of how to calculate the derated capacities, fresh-
water production and exhaust gas amounts and
temperatures will be described in details.
Nomenclature
In the following description and examples of the auxiliary machinery capacities, freshwater generator pro-
duction and exhaust gas data, the below nomenclatures are used:
Engine ratings Point / Index Power Speed
Nominal MCR point L
1
P
L1
n
L1
Specified MCR point M P
M
n
M
Optimising point O P
O
n
O
Service point S P
S
n
S
Fig. 6.01.01: Nomenclature of basic engine ratings
Fig. 6.01.02: Nomenclature of coolers and volume flows, etc.
Parameters
Q = Heat dissipation
V = Volume flow
M = Mass flow
T = Temperature
Cooler index
air scavenge air cooler
lub lube oil cooler
jw jacket water cooler
cent central cooler
Flow index
sw seawater flow
cw cooling/central water flow
exh exhaust gas
fw freshwater
