Man B&W L35MC6-TII User Manual

MAN B&W 3.01
Page 1 of 1
MAN Diesel
198 75 09-1.0MAN B&W L35MC6-TII
Turbocharger Selection
Updated turbocharger data based on the latest
information from the turbocharger makers are
available from the Turbocharger Selection
program on www.mandiesel.com under
‘Turbocharger’ → ‘Overview’ → ‘Turbocharger
Selection’.
The data specified in the printed edition are valid
at the time of publishing.
The MC/ME engines are designed for the applica-
tion of either MAN Diesel, ABB or Mitsubishi (MHI)
turbochargers.
The turbocharger choice is made with a view to
obtaining the lowest possible Specific Fuel Oil
Consumption (SFOC) values at the nominal MCR
by applying conventional turbochargers.
The engines are, as standard, equipped with as
few turbochargers as possible, see the table in
Fig. 3.01.01.
One more turbocharger can be applied, than the
number stated in the tables, if this is desirable due
to space requirements, or for other reasons. Ad-
ditional costs are to be expected.
However, we recommend the ‘Turbocharger se-
lection’ programme on the Internet, which can be
used to identify a list of applicable turbochargers
for a specific engine layout.
For information about turbocharger arrangement
and cleaning systems, see Section 15.01.
Fig. 3.01.01: Conventional turbochargers
Conventional turbochargers for the L35MC6-TII engines  L
1
output
Cyl. MAN (TCR) ABB (TPL) ABB (A100) MHI (MET)
5 1 x TCR20-21 1 x TPL65-BA10 - 1 x MET33MA
6 1 x TCR22-21 1 x TPL69-BA10 - 1 x MET33MA
7 1 x TCR22-21 1 x TPL69-BA10 1 x A165-L32 1 x MET42MA
8 1 x TCR22-21 1 x TPL69-BA10 1 x A165-L34 1 x MET42MA
9 1 x TCR22-21 1 x TPL73-B11 1 x A165-L35 1 x MET42MA
10 2 x TCR20-21 2 x TPL65-BA10 - 2 x MET33MA
11 2 x TCR22-21 2 x TPL65-BA10 - 2 x MET33MA
12 2 x TCR22-21 2 x TPL69-BA10 - 2 x MET33MA
