MAN B&W 19.04
Page 1 of 1
MAN Diesel
MAN B&W L35MC 198 65 81-3.0
Dispatch pattern, list of masses and dimensions
Table 19.04.01: Dispatch pattern
The weights stated are for standard engines with semibuilt crankshaft with forged throws, crosshead guides inte-
grated in the frame box, and MAN Diesel turbocharger. The final weights are to be confirmed by the engine supplier,
as variations in major engine components due to the use of local standards (plate thickness etc.), size of tuning wheel,
type of turbocharger and the choice of cast/welded or forged component designs may increase the total weight by up
to 10 %. All masses and dimensions in the dispatch pattern are therefore approximate and do not include packing and
lifting tools.
Note: Some engines are equipped with moment compensator and/or tuning wheel.
However, the weights for these components are not included in dispatch pattern.
Pattern Section
5 cylinders 6 cylinders 7 cylinders 8 cylinders 9 cylinders
Mass Length Mass Length Mass Length Mass Length Mass Length
in t in m in t in m in t in m in t in m in t in m
A1+B1 Engine complete
59.7 5.8 67.8 6.4 77.4 7.2 85.9 7.8 94.1 8.4
A2+B2
Top section 25.9 5.8 29.4 6.4 34.1 7.2 37.7 7.8 41.2 8.4
Bottom section 32.4 4.3 36.9 4.9 41.5 5.5 46.2 6.1 50.8 6.7
Remaining parts 1.4 1.6 1.8 2.0 2.2
A3+B3
Top section 25.9 5.8 29.4 6.4 34.1 7.2 37.7 7.8 41.2 8.4
Frame box section 10.8 3.5 12.7 4.1 14.6 4.7 16.5 5.3 18.4 5.9
Bedplate/Crankshaft 21.6 4.3 24.2 4.9 26.9 5.5 29.7 6.1 32.4 6.7
Remaining parts 1.4 1.6 1.8 2.0 2.2
Pattern Section
10 cylinders 11 cylinders 12 cylinders
Mass Length Mass Length Mass Length Height Width
in t in m in t in m in t in m in m in m
A1+B1 Engine complete
111.2 10.1 120.1 10.7 128.3 11.3 5.7 3.4
A2+B2
Top section 50.0 10.1 54.1 10.7 57.5 11.3 3.6 3.4
Bottom section 58.4 7.7 63.0 8.3 67.7 8.9 3.3 2.0
Remaining parts 2.8 3.0 3.2
A3+B3
Top section 50.0 10.1 54.1 10.7 57.5 11.3 3.6 3.4
Frame box section 21.4 6.8 23.3 7.4 25.2 8.0 1.6 1.7
Bedplate/Crankshaft 37.0 7.7 39.7 8.3 42.5 8.9 2.0 2.0
Remaining parts 2.8 3.0 3.2
