MAN Diesel
MAN B&W S50MC6, S50MC-C/MEC7/8, S50ME-B8/9,
S46MC-C7/8, S46ME-B8, S42MC7, S40ME-B9, S40MC-C9,
S35MC-C9, S35MC7, L35MC6, S35ME-B9, S26MC6
198 40 699.4
Exhaust Gas Pipes
Fig. 15.02.01b: Exhaust gas pipes, with turbocharger located on exhaust side of engine, option 4 59 123
121 15 27-9.2.0
TI 8707
PI 8706 TI 8701
TC 8701 I AH YH
*)
TC 8702 I AH AL YH YL
*) AL: Deviation alarm/Cylinder ±50ºC
YL: Deviation alarm/Cylinder ±60ºC
ForeAft
Exhaust gas receiver
To scavenge air receiver
Turbocharger
Flange connection D
ST 8801 IR
PI 8601
TI 8702
The letters refer to ‘List of flanges’
The position numbers refer to ‘List of instruments’
The piping is delivered with and fitted onto the engine
178 38 692.2
Fig.15.02.01a: Exhaust gas pipes, with turbocharger located on aft end of engine, option 4 59 121
Cyl. 1
Flange connection D
Turbocharger
To scavenge air receiver
Exhaust gas receiver
PI 8706
PI 8601
TI 8702
TI 8701
TC 8701 I AH YH
ST 8801 I
TI 8707
*) AL: Deviation alarm/Cylinder ±50ºC
YL: Deviation alarm/Cylinder ±60ºC
*)
TC 8702 I AH AL YH YL
The letters refer to list of ‘Counterflanges’
The item no. refer to ‘Guidance Values Automation’
