Slow down for UMS – Class and MAN Diesel requirements
Table 18.04.03: Slow down functions for UMS
ABS
BV
CCS
DNV
GL
KR
LR
NK
RINA
RS
IACS
MAN Diesel
Sensor and
function Point of location
1 1 1 1 1 1 1 1 1 1 1 1 TE 8106 YH Thrust bearing segment
1 1 1 1* 1 1 1 1 1 1 1 1 PT 8108 YL Lubricating oil inlet to main engine
1 1 TE 8112 YH Lubricating oil inlet to main engine
1 1 1 1 1 1 1 1 1 1 1 TE 811 YH Piston cooling oil outlet/cylinder
1 1 1 1 1 1 1 1 1 1 1 FS 8114 YL Piston cooling oil outlet/cylinder
1 TE 812 YH Main bearing oil outlet temperature/main bearing
(Only MC types 42-26)
1 XC 8126 YH Bearing wear (K98MC6/7 and all MC-C types)
1 1 1 1 1 1 1 1 1 1 1 PT 8401 YL Jacket cooling water inlet
1 1 1 1 1 1 1 1 1 1 1 1 TE 8408 YH Jacket cooling water outlet, cylinder/cylinder
1 1 1 TE 8609 YH Scavenge air receiver
1 1 1 1 1 1 1 1 1 1 1 1 TE 8610 YH Scavenge air box re-alarm, cylinder/cylinder
1 1 1 TC 8701 YH Exhaust gas before turbocharger/turbocharger
1 1 1 1 1 1 1 1 1 1 1 TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder
1 1 TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder,
deviation from average
1 WT 8812 YH Axial vibration monitor 2)
1 1 1* 1 1 1 1 1 1 1 XS 881 YH Oil mist in crankcase/cylinder
1 Indicates that the sensor is required.
The sensors in the MAN Diesel column are included for Unattended Machinery Spaces (UMS), option: 4 75 127.
The sensor identication codes and functions are listed in Table 18.07.01.
The tables are liable to change without notice, and are subject to latest class requirements.
2) Required for: K-MC-C6/7 and K98MC6/7 engines with 11 and 14 cylinders.
S-MC-C7/8 and L-MC-C7/8 engines with 5 and 6 cylinders.
(For 9-12 cylinder S42MC7, L5MC6, and S26MC6 data is available on request).
Select one of the alternatives * Or shut down
Or alarm for low ow * Or shut down
Or alarm for overheating of main, crank and crosshead bearings, option: 4 75 14.
See also
Table 18.04.04: Shut down functions for AMS and UMS
