MAN B&W 15.06
Page 2 of 3
MAN Diesel
198 64 13-7.0MAN B&W L35MC6
Two turbochargers located on exhaust side
$!
$"
$"
$#
Fig. 15.06.01b: Vectors of thermal expansion at the turbocharger exhaust gas outlet ange, TC on exhaust side
078 87 11-1.0.0b
Table 15.06.02b: Max. expected movements of the exhaust gas ange resulting from thermal expansion, TC on exhaust side
No. of cylinders 10-12 10 11 12
Turbocharger DA DB DC DC DC
Make Type mm mm mm mm mm
MAN Diesel
TCR22 * * * * *
NA34 * * * * *
ABB
TPL65 * * * * *
TPL69 * * * * *
MHI
MET33 * * * * *
MET42 * * * * *
*) Data is available on request
DA: Max. movement of the turbocharger ange in the vertical direction
DB: Max. movement of the turbocharger ange in the transversal direction
DC: Max. movement of the turbocharger ange in the longitudinal direction
