Changeover valves
Changeover valve
of type with con-
stant cross section
ζa = 0.6 to .2
ζb = .0 to .5
ζc = .5 to 2.0
Changeover valve
of type with volume
ζa = ζb = about 2.0
M: Measuring points
Fig. 15.05.01: Pressure losses and coefcients of resistance in exhaust pipes
178 32 091.0 178 06 853.0
R = D ζ = 0.28
R = .5D ζ = 0.20
R = 2D ζ = 0.7
R = D ζ = 0.6
R = .5D ζ = 0.2
R = 2D ζ = 0.
ζ = 0.05
R = D ζ = 0.45
R = .5D ζ = 0.35
R = 2D ζ = 0.30
ζ = 0.4
Outlet from ζ = .00
top of exhaust
gas uptake
Inlet (from
turbocharger) ζ = – .00
Pressure losses and coefcients of resistance in exhaust pipes
